NADav-receivers
NAD T 778
Equipment Sales & Professional Installation
MPN: T778
- 9.2 Channels
- Dirac Live room correction
- HybridDigital amplification
- MDC modular design for upgrades
- HDMI connectivity
- High-resolution music streaming
- Multiple subwoofer outputs
Specifications
Amplifier
| 8 Ohms | 140W (21.5dBW) |
|---|---|
| 4 Ohms | 170W (22.3dBW) |
| Full Disclosure Power (all channels driven simultaneously at full bandwidth at rated distortion) | 9 x 85W |
| 8 Ohms | 165W (22.2dBW) |
| 4 Ohms | 280W (24.5dBW) |
IM distortion at 1/3 rated power
| Damping factor | >300 (20Hz-1kHz, 8 ohms) |
|---|---|
| Input sensitivity and impedance | 1.12Vrms (ref. 8 Ohms, VOL at 0dB) |
| Frequency response | +0.3/-0.8dB (ref. 1kHz, 20Hz-20kHz) |
| Signal/noise ratio | >100dB (ref. rated power at 8 Ohms, A-Weighted) |
| Signal/noise ratio | >85dB (ref. 1W at 8 Ohms, A-Weighted) |
Preamplifier
| Frequency response | +/-0.3dB (ref. 20Hz - 20kHz) |
|---|---|
| Signal-to-noise ratio | >100dB (ref. 2V, A-Weighted) |
Total harmonic distortion
| Input sensitivity | 245mVrms (ref. 2V) |
|---|---|
| Maximum output level | >4.5Vrms |
| Input Sensitivity | 6.2mVrms (ref. 2V)(ref. 20Hz - 20kHz) |
| Signal-to-noise ratio | >80dB (ref. 2V, A-Weighted) |
| Maximum Input Level | >90mVrms (1kHz) |
Dimension and Weight
| Unit Dimensions (W x H x D) | 435 x 140 x 430mm (Gross)* |
|---|---|
| Net Weight | 12.1kg (26.7lb) |
| Shipping Weight | 15.5kg (34.2lb) |
