Biampconferencing
Biamp Modena MAX Connect Wireless BYOM Hub
Equipment Sales & Professional Installation
MPN: MAXCONNECT
- Wireless content sharing via AirPlay, Google Cast, HDMI, or USB-C
- Rebroadcast shared content to as many as 30 participant devices
- USB and HDMI connectivity for microphones, cameras, and speakers
- Workplace Ready for cloud-based management, monitoring, and updates
- Optional Auditorium Mode extends sharing to 200 devices and 6 displays
- Built-in whiteboard and annotation tools for interactive collaboration
- Covered by Biamp Systems' three-year warranty
Specifications
General
| Height | 1 inch (30 mm) |
|---|---|
| Width | 5 inches (132 mm) |
| Depth | 5 inches (132 mm) |
| Weight | 1.2 lbs (0.538 kg) |
| Mounting | Mounting plate with cable retainer (included) |
Environmental
| Operating Temperature | 20° - 60° C |
|---|---|
| Humidity | 10% - 90% |
Power
| Power | External power adapter 12V, 2A DC |
|---|---|
| Consumption | Standby 0.3W, max 7W |
Compliance
| Certifications | CB, HDMI, BQB, CE, FCC, RCM, REACH, RoHS, WEEE, CA65, SVHC233, TSCA |
|---|
Documents
